RI

Model

Custom Traditional, ADA Roll-In

Pan Size

Variable (cannot be larger than 20 square feet)

Material

Cast Marble

Floor Pattern

Traditional

Finish

Matte, Textured, Non-Slip

Backwall

Variable - Up to 120" max on master

Side Walls

Variable - Up to 60" max on master

Drain Location

Must fit limitations of mold

Center of Drain Measures

Variable - based on final pan size

Drain Opening

3 1/4"

Front Curb

None. Floor will tile up to the entrance of the pan forming the ramp

Ramp

Provided by others

Flange

4" on side and back walls - attached at factory

Weight

Variable by size

Slope

Pan is sloped toward the drain at 2%
